半自涂膜完整性测定仪

SI9200 半自涂膜完整性测定仪

请注意：要使用此仪表，您还需要 Sencon 罐头支架或适配器，如配件选项卡下所示的那些。

选项和配件

产品能力

Sort:

1

ProductPage:

SI9200

Maximum Batch Size:

1 to 99 cans

Measurement Features:

Lacquer leakage current (rating current)

Accuracy:

±1% (0 to 100mA range)

Rating Duration:

2s to 99s

Capacity:

Data Storage: 2000 readings (approximately)

规格

Sort:

1

ProductPage:

SI9200

Voltage:

100 – 240 V, single phase, 47 or 63 Hz

Temperature Range:

0°C to 45°C (32°F to 113°F)

Relative Humidity:

0% to 80% non-condensing

Ingress Protection:

IP65

Controller:

7 inch color TFT LCD with wide viewing angle, icon-driven interface, and tactile membrane keypad

Measurement Reporting:

Measurements displayed on LCD display
Measurements can be output to PC or printer over serial RS232

Inputs and Outputs:

8-pin connector for connecting to accessories (see accessories for compatible can stands)
Data output: RS232 serial connector (for connecting to PC or printer) 150, 300, 600, 1200, 2400, 4800, 9600, 19200 baud

Dimensions:

175mm x 270mm x 100mm (6.88" x 10.63" x 3.93")

Weight:

1.2kg (2.6lb)

Compliance:

CE marked: complies with relevant EU product directives. UKCA marked: complies with relevant UK product regulations.

Calibration:

Annual calibration is strongly recommended

由于产品不断开发，实际规格可能会发生变化。电&OE

直接下载

用户手册

SI9100 Semi-auto Enamel Rater User Manuals User manuals in English, Français, Deutsch, Español SI9100 Additional Information for Supervisors.pdf 23.5 Kb Download SI9100 Semi-Auto Enamel Rater User Manual [English].pdf 1.2 Mb Download SI9100 Semi-Auto Enamel Rater User Manual [French].pdf 1.4 Mb Download SI9100 Semi-Auto Enamel Rater User Manual [German].pdf 1.2 Mb Download SI9100 Semi-Auto Enamel Rater User Manual [Spanish].pdf 1.3 Mb Download _SI9200 Semi-Auto Enamel Rater User Manual [English].pdf 4 Mb Download Knowledge Base Software by: KnowledgeBase Manager Pro v6.2.2 (Built with: JS.GUI - IT Helpdesk)

其他资源

Enamel Rating Reference Guide This reference guide is a collection of useful information relating to the widely used enamel rating test. The test itself is quite simple, but why it works and how to get the best from the test is not necessarily well known. Can Stand Level Probe Modification.pdf 0.1 Mb Download Enamel Rating Reference Guide v1.1.pdf 0.4 Mb Download Knowledge Base Software by: KnowledgeBase Manager Pro v6.2.2 (Built with: JS.GUI - IT Helpdesk)
