CAN ENDS/LIDS DIMENSIONS
Sencon manufactures a range of products for makers of standard sanitary and easy-open ends (EOE) for both food and beverages - from fully automatic gauges to sensors that manage the line to on-press light detection which identifies defective ends on the conversion press. Sencon’s range of products for Shell and Tab manufacturers has been developed over many years of experience within the canmaking industry. View the complete range of Sencon equipment for Shell, End and Tab manufacturers here.
CAN ENDS/LIDS DIMENSIONS
IMPERIAL SIZE |
METRIC SIZE (mm) |
| 112 | 44.5 |
| 113 | 46 |
| 200 | 51 |
| 202 | 54 |
| 206 | 60 |
| 209 | 65 |
| 211 | 68 |
| 214 | 73 |
| 300 | 76 |
| 303 | 81 |
| 305 for dia. 307 necked in cans | 84 |
| 307 | 87 |
| 309 | 90 |
| 314 | 98.5 |
| 315 | 100 |
| 400 | 101.5 |
| 401 | 103 |
| 402 | 105 |
| 404 | 108 |
| 411 | 119 |
| 502 | 130 |
| 508 | 140 |
| 514 | 149 |
| 603 | 157 |
| 611 | 163.5 |
| 700 | 178 |
| 710 | 193.5 |
| 800 | 203 |
| 804 | 209.5 |
| 808 | 216 |
| 810 | 219 |
| 903 | 233 |
| 906 | 238 |
| 914 | 251 |
| 1314 | 352.5 |
