2-PIECE DWI CAN DIMENSIONS

For accurate measurement of beverage can dimensions see the our latest semi-automatic Benchtop Gauges: Benchmark™ Front End Gauge; Benchmark™ Back end Gauge and our fully automatic Master Series™ Front end and Master Series™ Back End gauges.

Can body and neck diameters, as well as end/lid sizes, are traditionally expressed in inches plus sixteenths of an inch. For example: '202' nominally stands for 2 2⁄16" (≅ 54mm) ; '211' nominally stands for 2 11⁄16" (≅ 68mm).

EUROPEAN CAN DIMENSIONS

IMPERIAL VOLUME

 METRIC VOLUME
(ml)

IMPERIAL SIZE
(inches + 1⁄16ths)

 METRIC SIZE
(mm)
150 202 x 308 54 x 89
150 200/202 x 308 51/54 x 89
202/211 x 408 54/68 x 114
250 202 x 504 54 x 133
10 imp fl oz 275 206/211 x 315 60/68 x 100
11.6 imp fl oz 330 206/211 x 408 60/68 x 114
330 202/211 x 408 54/68 x 114
12 imp fl oz 341 206/211 x 410.5 60/68 x 118
16 imp fl oz 440 206/211 x 513 60/68 x 148
18 imp fl oz 500 206/211 x 610 60/68 x 168

USA CAN DIMENSIONS

IMPERIAL VOLUME

 METRIC VOLUME
(ml)

IMPERIAL SIZE
(inches + 1⁄16ths)

 METRIC SIZE
(mm)
8 US fl oz 236 202/204 x 413 54/57 x 122
236 206/211 x 306 60/68 x 86
12 US fl oz 355 207.5/209 x 504 63/65 x 133
355 206/211 x 413 60/68 x 122
355 204/211 x 413 57/68 x 122
355 202/211 413 54/68 x 131
355 204/209 x 504 57/65 x 129
16 US fl oz 473 206/211 x 604 60/68 x 156

ASIA CAN DIMENSIONS

IMPERIAL VOLUME

 METRIC VOLUME
(ml)

IMPERIAL SIZE
(inches + 1⁄16ths)

 METRIC SIZE
(mm)
325 206/211 x 408 60/68 x 114
350 206/211 x 413 60/68 x 122

AUSTRALIAN CAN DIMENSIONS

IMPERIAL VOLUME

 METRIC VOLUME
(ml)

IMPERIAL SIZE
(inches + 1⁄16ths)

 METRIC SIZE
(mm)
13 imp fl oz 375 206/211 x 501 60/68 x 129
26 imp fl oz 750 300/307 x 604 76/87 x 156
